RS-D7104HR-N-T/RS-D7108HR-N-T
Return to list page
Record Bandwidth IP Cam Inputs
24Mbps ~72Mbps, IP Bandwidth default is 24Mbps,
Recording Resolution out
72Mbps
Display resolution
Analog : 8MP（15fps）,5MP（20fps）,4MP/1080P/720P/960H （30fps）
IP: 4K/4MP/1080P/720P
Speed
Analog :8MP:7fps(each ch), 5MP:12fps(each ch), 4MP:15fps(each ch),
1080P:PAL:25fps(each ch)/NTSC:30fps(each ch)
IP:PAL:25fps(each ch)/NTSC: 30fps(each ch)
8MP: 60fps （Max 4CH playback）,5MP: 96fps（Max 8CH playback）,
4MP: 120fps （Max 8CH playback）,1080P: 240fps （Max 8CH playback）
Intelligent
PID ,LCD
Internal HDD
1 SATA HDD, up to 10TB default (Design reserved 2HDD)
Alarm Input/out
8 in /1 out optional, not supported by default
300X227X53mm
Operating Temperature/Humidity
Temperature : -10°C~+50°C (14°F ~ 122°F)
Humidity : Less than 90%RH
| Model Name | RS-D7104HR-N-T | RS-D7108HR-N-T | |
| Recording Bandwidth | Inputs | 12Mbps ~36Mbps, IP Bandwidth default is 12Mbps, | 24Mbps ~72Mbps, IP Bandwidth default is 24Mbps, |
| out | 48Mbps | 72Mbps | |
| Analog video-input | 4CH inputs | 8CH inputs | |
| Live | IP Video Input | 2ch,(only IP up to 6ch) | 4ch,(only IP up to 12ch) |
| Composite Video Input | up to 6ch (Analog video + IP video) | up to 12ch (Analog video + IP video) | |
| Performance | |||
| Recording and Playback | Compression | Audio: G.711a ;Video : H.264/H.265 | |
| Display resolution |
Analog : 8MP（15fps）,5MP（20fps）,4MP/1080P/720P/960H （30fps） IP: 4K/4MP/1080P/720P |
||
| Speed |
Analog :8MP:7fps(each ch), 5MP:12fps(each ch), 4MP:15fps(each ch), 1080P:PAL:25fps(each ch)/NTSC:30fps(each ch) IP:PAL:25fps(each ch)/NTSC: 30fps(each ch) |
||
| Event |
MD(Sensitivity Level 1~8) Videlo lossBeep, |
||
| Playback function |
Fast forward / backward (2x, 4x, 8x,16x) Slow forward (1/2x, 1/4x, 1/8x,1/16x) |
||
| Playback | 8MP: 28fps, 5MP: 48ps, 4MP: 60fps, 1080P: 120fps | 8MP: 60fps （Max 4CH playback）,5MP: 96fps（Max 8CH playback）,4MP: 120fps （Max 8CH playback）,1080P: 240fps （Max 8CH playback） | |
| Intelligent | PID ,LCD ,PD&VD | PID ,LCD | |
| P/W Reset | Factory Reset : Press 10 seconds | ||
| Monitors | BNC | 1 (704*576) | |
| VGA | 1（1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 ） | ||
| HDMI | 1（1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 , 2560*1440, 3840*2160/EDID） | ||
| Ethernet | 1 RJ45 10/100 Base-T1 RJ45 100/1000 Base-T | ||
| USB | USB2.0*1(front), USB2.0*1+(rear) | ||
| Audio | 4 in / 1 out | 4 in / 1 out (Max 8 in /1 out optional,) | |
| E-sata | 1 optional, not supported by default | ||
| HDD | 1 SATA HDD, up to 10TB default (Design reserved 2HDD) | ||
| RS485 | 1 | ||
| Alarm Input/out | 4 in /1 out optional, not supported by default | 8 in /1 out optional, not supported by default | |
| General | |||
| Mechanical design | Dimension (WxDxH) | 300X227X53mm | |
| Electrical | Input Voltage/Current | 1HDD:DC12V/2A, 2HDD:DC12V/5A | |
| Power consumption (excluding hard disk) | 4.7W | 11W | |
| Environmental | Operating Temperature/Humidity | Temperature : -10°C~+50°C (14°F ~ 122°F), Humidity : Less than 90%RH | |
